Integrating Bryntum Scheduler with React

This post is outdated. You can find the up-to-date guide here.

React is a very popular JavaScript framework for interactive UIs. With our new pure JS component suite, you can easily add a very powerful Grid or Scheduler component to your React apps. This post will show you how to get started with integrating the new Bryntum Scheduler in your React project.

The Scheduler as a React component

The React demos included with the Scheduler contain a basic React component called BryntumScheduler that uses the Scheduler as its engine. In this post we will outline the steps needed to add it to your project and also take a look at how to use it. To see React demos in action, visit /products/scheduler/examples/#Integration/React.

Adding the Scheduler component to your React project

To add the component to your project:

1. Copy BryntumScheduler.jsx from /examples/react_build/components to your project.
2. Make sure the path to scheduler.model.js in the copied file is correct for your setup
3. Copy the css for the theme you want to use from /build to your project.
4. Include the css file on your page:

   <link rel="stylesheet" href="scheduler.default.css">

5. Import the component in your app:

   import BryntumScheduler from './components/BryntumScheduler.jsx';


Using the Scheduler component

After including/importing the required files you can use the <BryntumScheduler>-tag to create a scheduler. It supports many of the configuration options available for Scheduler as attributes/properties. A basic example, in your render() function:

<BryntumScheduler
    ref={'scheduler'}
    eventsVersion={this.state.eventsVersion}
    resourcesVersion={this.state.resourcesVersion}
    events={this.state.events}
    resources={this.state.resources}

    startDate={new Date(2018, 9, 17, 8)}
    endDate={new Date(2018, 9, 17, 18)}
  ></BryntumScheduler>

The definition above populates the scheduler with events and resources from React state. To prevent a full redraw on each state update it uses version numbers for the dataset supplied (eventsVersion and resourcesVersion above). For example to load data when the component mounts:

componentDidMount() {
    const scheduler = this.refs.scheduler;

    fetch('data/data.json').then(response => {
        response.json().then(data => {
            this.setState({
                // Increment these to notify BryntumScheduler that it should process events/resources again
                eventsVersion : 1,
                resourcesVersion : 1,

                events     : data.events.rows,
                resources  : data.resources.rows,
                timeRanges : data.timeRanges.rows
            });
        });
    });
}
});

Accessing the engine

While the BryntumScheduler component wraps the scheduler configuration you will need to access the underlying engine to harness its full power. It is available as a property of the component, called schedulerEngine. Below is a one-line example how to use the engine to access the resource store and add a new resource:

// Since our BryntumScheduler tag above contained a ref for the component
// we can access it easily
this.refs.scheduler.schedulerEngine.resourceStore.add({ name : 'New resource' });

Learn more

The best way to learn more about the React Scheduler component is to examine its source and the demo. And to learn more about the Scheduler API, please visit the docs. If you have not already, please download our trial version and check it out.

Feel free to extend the React component with what you need, and please also share your thoughts on our forum. The React component wrapper will be extended according to popular demand, but remember that you can always access the underlying engine if a feature or config is not exposed directly. Some useful links:

• Scheduler product page
• Scheduler docs
• Scheduler examples

Summing up

The Bryntum Scheduler works with React out of the box and ships with a demo containing a basic React component. And although the React component does not wrap all functionality in Scheduler, you can always access the engine to use any part of the API.

Good luck!
